Emerson and Renwick Gravure Coater with Flotation Drying

Polygraphica are delighted to offer for sale a very rare and highly specified Emerson and Renwick Gravure Press with Gas Flotation Drying, manufactured only in 2013.

Very rare to the used market, this press cost £ 1,700,000 to install only 2 years ago!! The press has been in almost cleanroom surroundings and is in as new condition, with no signs of wear or tear.  The press is now available for a fraction of the ‘New’ price.

Please check out the full specifications and a small number of photographs below.

EMERSON & RENWICK 3 STATION GRAVURE COATING LINE
Year of manufacture: 2013
Machine originally designed for scratch-free optical quality coatings
Coating station 1 for solvent based coatings, stations 2 and 3 for aqueous coatings
All stations with 2 removable coating modules for coating on each side of web
Maximum web width: 510mm
Minimum web width: 300mm
Coating method: Reverse, Kiss Gravure coating with enclosed chamber doctor blades
Gas powered 3 station air floatation drying dryers of lengths: 2.125    4.375 and  4.375 metres
Automatic unwind/rewind for maximum 500mm diameter rolls
Secondary unwind with manual splice for interleaf material
LEL solvent concentration monitoring system
Film thickness measuring system
Dr. Shenk inspection system

Main substrates processed:
Material: A PET
Thickness: 30–50µ
Material B: Polycarbonate
Thickness: 30–50µ
Interleaf
Material – natural single wound Polythene
Thickness: 30µ

Maximum mechanical speed: 55m/min
Process speed range: 5–50m/min
Double side coating: 25m/min
Single side coating: 50m/min
Thread up: 5m/min, adjustable



Contact sales@polygraphica.com for more information on this hard to source press.

Emerson and Renwick

Emerson and Renwick

Emerson and Renwick

Emerson and Renwick

Emerson and Renwick

Emerson and Renwick

Emerson and Renwick

Emerson and Renwick
