Cement Sack Production Line

Polygraphica have available for sale the following Windmoller and Holscher Sack Line, with 2 colour inline printer, for the production of heavy duty sacks.

Manufactured in the mid-1980’s, the line is immediately available and can be demonstrated prior to any sale.

W&H PAPER SACK LINE

Comprising of:
Windmoller & Holscher Tuber + Bottomer
Typical sacks produced: 20-50kgs for cement

Tuber –
Stepped end perforation and flush cut
Tube width when working flat tubes: 58 – 123cm
Tube width when working gusseted tubes: 52 – 123cm
Tube width when working
Tube lengths with flush cut: 55 – 165cm
Tube lengths with stepped ends: 55 – 132cm
Paper reel width maximum: 133cm
Paper reel diameter maximum: 130cm
Core id: 7.6cm
Inline 2 Colour Printer
Unwind stands x 4

Valve Sack Bottomer
Tube width 40-55cm
Bottom width: 8.5 – 12cm
Tube length (stepped end) minimum 55 – 93cm
Tube length (stepped end) maximum 65 – 100cm
Sack length (stepped end) minimum 43.5 – 78.5cm
Sack length (stepped end) maximum 47 – 83cm
Bottom centre distance (stepped end) minimum 35 – 70cm
Bottom centre distance (stepped end) maximum 35 – 70cm
Valve cut off length: 14cm
Valve reel width: 13.5-17cm

If you require further information please contact me and register your interest. Please include full details of your Company and a telephone number as all interest will need to be ratified and endorsed prior to information being sent.

ETI Label Converting Line

Polygraphica have available for sale the following ETI Coating Machine for the manufacture of your own label stock.

ETI Label Coating Line
Year of Manufacture: 2007
Material width: 250mm to 540mm
Material thickness range: 20 micro to 150 micro

Max roll unwind diameter: 850mm
Brake: magnetic powder brake
Deflection shaft 79mm
Antistatic
Corona pretreatment
Vectra 520mm Semi-automatic rewind
Inspection system: AVT
Lamination: YES
Adhesive coating: hot melt with curtain nozzle: full surface partial in LFR
Crushing knife / Diecut
2 X turn crosses
Siliconization possible with N2 (UV silicon)
Hotemelt Application weight: 15 – 35g / m2

If you would like any further information, on the above machine please telephone +44 1924 200444 or email sales@polygraphica.com

http://www.polygraphica.com

Used Uteco Flexo Presses For Sale

Polygraphica have available for sale the following Uteco Flexo Presses for sale.

The used flexo presses are in excellent running condition and can be deomnstrated prior to any sale.

UTECO DIAMOND HP108 – GEARLESS CI FLEXO PRESS
Year of Manufacture: 2011
Number of colours: 10
Fast sleeve change
4 motor per deck CNC position system
Computer supervision
Web width: 1550mm – Print width: 1500mm
Print repeat range: 420mm – 870mm
Automatic Turret Unwind and Rewind: 1000mm diameter
Drying: 2 zones 4 fans with 6mt final tunnel and thermo oil heat exchangers
Video camera: Grafikontrol with 100% inspection system
Web guides: BST in and out
Viscosity control: automatic
Washing system: automatic
Inking system: closed chamber doctor blades, 10 + 2 spares
Carbon fiber mandrels
Drum cleaning device

UTECO ONYX 808 – GEARLESS CI FLEXO PRESS
Year of Manufacture: 2006
Number of colours: 8
Fast sleeve change
4 motor per deck CNC position system
Computer supervision
Web width: 1250mm – Print width: 1200mm
Print repeat range: 360mm – 760mm
Turret unwind and rewind – with 800mm diameters
Drying: 2 zones, 4 fans with inverter, tunnel 4mt length, 2 gas burners
Video camera: BST Super Handyscan 3000

UTECO ONYX 808 – GEARLESS CI FLEXO PRESS
Year of manufacture: 2011
Number of colours: 8
Fast sleeve change
4 motor per deck CNC position system
Computer supervision
Web width: 1250mm – Print width: 1200mm
Print repeat range: 350mm – 800mm
Automatic Turret Unwind and Rewind – with 800mm diameters
Drying: 2 zones, 4 fans, tunnel 5 tm length, automatic air recirculation system with LEL control Nira
Video camera: Grafikontrol Grafiskan 2100
Corona treatment: Ferrarini Benelli
Web guides: BST
Viscosity control: automatic Gama
Washing system: automatic
Inking system: closed chamber doctor blades



If you are looking for a used Uteco flexographic press but the above are not to your exact requirements please look at our website for our latest offers on all available Uteco Flexo Presses. https://polygraphica.com/used-equipment/Uteco/

If you are looking for a flexographic press by any manufacturer, look at all the used flexo presses we have for sale: https://polygraphica.com/used-equipment/Flexographic_Presses/

Email:  sales@polygraphica.com

WhatsApp: +44 7938 998081

http://www.polygraphica.com

MPS EF410 – 8 Colour Advanced Label Press

Polygraphica has available for sale the following MPS EF 410, 8 Colour Label and Packaging Press.

The press is available in June 2020 and can be demonstrated prior to any sale. A recent video is below showing the current condition of the machine.

MPS EF410 APC ADVANCED LABEL AND PACKAGING PRESS
Year of Manufacture: 2008
With automated print pressure settings for both print sleeves and anilox
Unwind and rewind diameter: 850mm
Vetaphone corona: double sided
Teknek web cleaner: double sided
8 x UV flexo print stations with lean inking
GEW EBrick UV
Closed chambers + pumps
8 chill rolls
Rail system
Delam/relam
Turnbar
Multi drive system: auto pre register, multi pass
Rotary die station
3 IR cassettes, flexible positioning
Back slitting
UV lamination
Sheeter
Edge slitting (scissor)
Suppled with a good selection of anilox and print sleeves.


If you have any interest in the MPS EF 410 Label Press please email sales@polygraphica.com for more information. Alternatively you can telephone +44 1924 200444.

http://www.polygraphica.com

For Sale – Used MPS Label Presses

Are you looking for a used MPS Label Press?

Polygraphica have the following MPS Presses that are available immediately.

All are in excellent running condition and can be demonstrated prior to any sale.

MPS EF330 – 10 Colour Label and Packaging Press
Year of manufacture: 2008
Full servo press
Auto register control
Web cleaner & Corona treater
10 UV Flexo print stations with GEW E Brick UV x 10
Overhead rail system
Delam and relam unit
Web turn bar
Rotary die station with K & B Gap Master
Waste rewind unit
Upgraded BST camera system
Chill rolls
Varnish cylinder
Good selection of tooling supplied
Heaford plate mounter



MPS EF410 – 7 Colour Label & Packaging press
Year of manufacture: 2012
Full servo press
Standard unwind and infeed
Vetafone corona treater and Teknek web cleaner
7 UV flexo print stations with GEW E Brick UV
Chill rolls
Rail system
Delam/relam
Web Turn bar
Single die station



MPS EP410 – 8 Colour Label Press
Year of manufacture: 2003
Web width: 420mm
Print width: 410mm
Standard unwind and infeed
Corona treater
UV flexo print stations x 8
Hot air dryers x 6
Lamination
Die stations x 2
Standard rewinds



If you are looking for a used MPS Printing Press and the above are not to your exact requirements, please check our website to view all MPS Printing Presses we have available for sale: Polygraphica – MPS Presses For Sale







For Sale – Kampf Slitter & AC Servo Sheeter

Polygraphica have available for immediate sale the following Kampf Sheeter and a Servo Sheeter (from Taiwan)

Kampf Slitter Rewinder
Corona treater,
Air shafted single position unwind,
Side and centre slitter,
Independent waste trim extraction,
Single position rewind stand,
Guarding system,
RSJ hoist structure

Kampf Slitter Rewinder

Kampf Slitter Rewinder For Sale

Kampf Slitter Rewinder

Kampf Slitter Rewinder for Sale





Sheeter
AC Servo High Speed Precision sheeter:
Twin position unwind
Edge slitting,
Rotary knife,
Pallet delivery
Additional unwind unit



For more information please contact Mike Kennedy at sales@polygraphica.com or telephone +44 1924 200444.

Giftwrap Printing and Packaging Machinery

Polygraphica have available for sale the following Cobden Chadwick Flexographic Printers and Elsner Gift Wrap Rewinders.

The machines are all located in the same premises here in the UK and are all available immediately.

The machines are in full working condition and can be demonstrated prior to any sale.

2 x Cobden Chadwick CI flexo press
6 colours
Maximum web width 800mm
Currently used for printing Christmas wrapping paper

This slideshow requires JavaScript.

2 x Elsner Gift Wrap Rewinders – (one fully working, one for spares or repair)
Model HS800
With Shrink ovens

This slideshow requires JavaScript.

If you are interested in the above machines please contact Mike Kennedy on sales@polygraphica.com or telephone +44 1924 200444.

These machines need to move quickly and are priced accordingly, get in touch you may get the first bargain of 2020.



W + H Soloflex Press

Polygraphica have available for sale the following W&H Soloflex, 6 Colour Flexographic Press.

The press has been well maintained and is still in full production, so can be viewed in running condition.

W & H SOLOFLEX 6 COLOUR CENTRAL IMPRESSION
Year of manufacture: 1993

Maximum printing width: 600 mm
Material width: 620 mm
Printing length: 250–520mm
Roll diameter: 600mm
Drying: electric
Non stop unwind with pneumatic brakes
Non stop rewind with dc motor
Doctor blades
Gearing: 5mm
Including: 4 x 6 sets of print sleeves
Anilox sleeves x4
BST web control system
Temperature control unit

This slideshow requires JavaScript.

If you have any interest in the W&H Soloflex please contact Mike Kennedy at sales@polygraphica.com for more information.

http://www.polygraphica.com

Gallus CCS 510, 10 Colour Press For Sale

Polygraphica are delighted to be able to offer for sale the following Gallus CCS510 10 Colour Press.

The Gallus CCS 510 for ultimate flexibility in folding carton converting combines maximum process and production flexibility, easy process changeover and cost-efficient use of different value-add processes.

GALLUS CCS 510 FOLDING CARTON / LABEL PRESS
Year of manufacture: 2016

Unwind diameter: 1.525mm (60”)
Full press servo
Servo infeed with closed loop tension control
Teknek two sided web cleaner
Web break detector
Final web cleaner
Arcotec corona treater
Servo driven print stations x 10
GEW Nuva UV dryers with step less control x 10
Water cooled chill rollers x 10
Hot air dryers x 10
Sensotec auto register control system
Full rail system
Turnbar
Hot foil module
Rotary screen module + screen starter kit and mounter
3 x cold foil/lamination unwind/rewinds
Tidland slitting station
Rotary die station/rotary embossing station/window
Decurler
Rewind unit
BST Powerscope 3000 web inspection
Gallus FMS510
Sensotec infeed register control sensor
Servo driven flatbed die cutting unit, FSM510
Full out waste stripping unit
Delivery feeder
Shingle delivery conveyor for FSM 510
Window stripping
Heaford Cobra 600 XLS plate mounter
Chiller supplied
500 job storage

This slideshow requires JavaScript.



If you require any further information on the Gallus CCS 510 please email sales@polygraphica.com or telephone +44 1924 200444.

Curioni Sun Master 540 – Paper Bag Making Machine

Polygraphica have available for sale the following Curioni Sun Master 540 paper bag making machine, with handles.

CURIONI SUN MASTER 540
Year of manufacture: 1996, (full mechanical overhaul 2004)

Feed: reel fed
Handle: twisted
Bag length maximum: 660mm
Bag length minimum: 310mm
Bag width maximum: 540mm
Bag width minimum: 220mm
Bottom width maximum: 220mm
Bottom width minimum: 90mm
Cycle/min 100 pcs/min

Additional information:
Handle units contain hot glue and water base glue for hot weather ambient
Machine can do the “J” cutting without glue



For more information including prices, please contact us:
email: sales@polygraphica.com
telephone +44 1924 200444 or
WhatsApp +44 7938 998081

http://www.polygraphica.com
