It is a pleasure that we can offer the following laminators and flexo printing presses.
All the machine are located in Europe and available immediately for inspection and purchase.
NORDMECCANCIA SUPER COMBI 2000 LAMINATOR
Year of manufacture: 2001
Laminator layers: 2; Duplex lamination
Type of lamination: combi, solventless and solvent/water based
Working width: 1300mm; Mechanical speed up to: 300m/min
Unwind 1st shaftless diameter reel maximum: 1000mm
Unwind 2nd shaftless diameter reel maximum: 1000mm
Rewind shaftless: diameter reel maximum: 1000mm
Coating unit with interchangeable trolleys
One rotogravure trolley for solvent and water based glue
one solventless trolley
Coating rollers as available
Pumping mixing unit: 2 component solventless adhesive
Drying: 6m drying tunnel with 2 independent hoods and 4 fans
Temperature regulation units x 3
Cold seal unit
Our Ref: W54681
COMEXI CL SOLVENTLESS LAMINATOR
Year of manufacture: 1998
Laminator layers: 2; Duplex lamination
Working width: 1370mm; Maximum laminating width: 1320mm
Mechanical speed up to : 250m/min
Unwind 1st diameter reel maximum: 800mm
Unwind 2nd diameter reel maximum: 1000mm
Unwind cores: 70, 76 or 150mm
Rewind diameter reel maximum: 1000mm; Rewind core: 150mm
Pumping mixing unit: 2 component solventless adhesive
Our Ref: W54680
NORDMECCANICA SIMPLEX SL SOLVENTLESS LAMINATOR
Year of manufacture: 1997
Laminator layers: 2; Duplex lamination
Working width: 1100mm; Speed: 315m/min
Unwind 1st: single shaftless; Unwind 1st: diameter reel maximum: 850mm
Unwind 2nd: single shaftless; Unwind 2nd: diameter reel maximum: 850mm
Rewind: single shaft less; Rewind: diameter reel maximum: 850mm
Pumping mixing unit: Contaldi; Coating rollers as available
Our Ref: W54675
UTECO ONYX 876 GL 120 8 COLOUR GEARLESS CI FLEXOGRAPHIC PRESS
Year of manufacture: 2009
Material: Paper; PP, PET, LDPE, subject to press tension range
Web width: 1250mm; Print width: 1200mm; Mechanical speed: 400m/min
Minimum speed approximately: 30m/min; Repeat range: 350–800 mm
Number of print stations: 8 with enclosed doctor blade systems
Computerized supervision; Sleeve change system; Gearless
TA U automatic turret unwind: 1000mm diameter
TA R automatic turret rewind: 1000mm diameter
Pneumatic expandable shafts: 76mm diameter
Real loading and unloading systems
Bow roller ; Pneumatic dancer roll for automatic control of web tension
Edge guide camber roll; Positioning of print unit decks by CNC motors 4 per deck
Remote control pendants; Drying: electric; Between colour and drying tunnel
Manual air recirculation; Video camera; Register control; Web guide: OPG with platform
Main operators control console
Services: electrics 400volts, 3phase 50hz; Compressed air supply: 6 bar capacity 750 litres/min
Our Ref: R54674
SOMA FLEX MINI 80 8 E 8 COLOUR FLEXOGRAPHIC CI PRESS
Year of manufacture: 2004
Fast sleeve change; 4 motor per deck CNC position system; Computer supervision
Web width: 850mm; Print width: 820mm;
Minimum print repeat : 260mm; Maximum print repeat: 600mm
Unwind: turret with maximum reel diameter of 800mm
Rewind: turret with maximum reel diameter of 800mm
Drying: electrical heaters; Fife video camera; Corona treatment; Web guides: 1 prior to printing
Maximum mechanical speed of machine: 300m/min
Spreader roller prior to printing and rewinding
Our Ref: R54663
FISCHER & KRECKE 34DF / 8 CNC CI FLEXOGRAPHICA PRESS
Year of manufacture: 1992
Number of colours: 8 with chamber doctor blade systems
Mechanical speed: 350mpm; Gear pitch: 10mm
Maximum web width: 1500m; Maximum print width: 1450mm
Minimum print repeat: 380mm; Maximum print repeat: 1000mm
Turret unwind, cores 76/152mm; Unwind diameter: 1000mm
Turret rewind, cores 76/152mm; Rewind diameter: 1000mm
Temperature control unit for CI; Drying: steam heaters
Web guides; Web viewer Eltromat; Viscosity control: Opticolour 2000
Ink tanks and pumps; Inline slitting; Anilox roller: as available; Print cylinders: as available
Our Ref: R54661
WINDMOELLER & HOLSCHER ASTRA FLEX 8 COLOUR CI FLEXOGRAPHIC PRESS
Year of manufacture: 2000
Maximum web width: 1620mm; Maximum print width: 1570mm
Print repeat: minimum/maximum: 400-1010mm
Number of colours: 8; Mechanical speed up to: 364m/min
Automatic turret unwind reel diameter: 1000mm
Automatic turret rewind reel diameter: 1000mm
Video camera web scope Fife and BST super handy scan 4000
Corona treatment; BST web guides
Anilox rollers: approximately 13 between 80L/cm – 340L/cm
including all parts gears & accessories available
Material: PE, LDPE, PP, Polyamide, HDPE, OPP, paper
Our Ref: R54660
UTECO EMERALD 8 Colour flexographic CI GEARLESS
Year of manufacture: 2001
Sleeve based and computer controlled, gearless
Maximum web width: 1250mm; Maximum print width: 1200mm
Print repeat: 350-760mm; Number of print stations: 8
Fully automatic motorized print station positioning with 4 motors per deck
Turret unwind maximum reel diameter: 800mm; Turret rewind maximum reel diameter: 800mm
Drying system: 2 zone, 4 fans thermal oil heat exchangers; Chiller Thermoregulation system
Video camera BST Proscan; Web guides; Automatic wash up system
Slitting device at rewind with rotary knives Helios type and trim exhaust
Our Ref: R54648
If you require any photographs or further information on any of the above machines please contact me at: sales@polygraphica.com
We look forward to being of service to you with your machinery requirements/disposals.
